DSR 1 Tactical Precision Rifle

Product Description

General description

The DSR 1 Rifle is “The most sophisticated and technologically advanced tactical precision rifle in the world.” Designed from the ground up by DSR’s technical team, this rifle meets or exceeds all mission requirements for a tactical precision rifle.

The concept and modular design of the DSR 1 allows it to be adapted to the different requirements of military and police snipers.

An advanced feature of the DSR-1 is its bull pup design. This configuration offers several advantages, not seen in traditional rifle designs. First, since the chamber of the barrel is located behind the trigger, the bull pup design allows for the use of a full length 26″ barrel while maintaining a short and compact overall rifle length (39″).

The bullpup design allows a straight, in-line barrel. Recoil forces are directed along a straight line, minimising muzzle rise.

The DSR-1 is designed around the .338 Lapua Magnum but also available in .308 Win. and .300 Win. Mag. The dimensions of the action enables it to be adapted to rounds with a head diameter up to .590 inches and a length of 3.810 inches.

The DSR-1 has a custom made heavy bench rest barrel of the highest quality to guarantee the accuracy that the ammunition is capable of. The bores and chambers are made with the most stringent requirements concerning minimum dimensions and concentricity. Barrels are stress relieved.

The DSR-1 is fully adjustable to the shooters requirements. The rifle has an ergonomic pistol grip. The butt stock is adjustable for length of pull and butt plate position. The height of the cheek piece is adjustable via a quick release spring button. The adjustable fore-end can also be used to rest the rifle on a sandbag. All adjustments can be accomplished within seconds and without tools via quick release tension levers. In addition, the positions are calibrated for easy reference.

An extended picatinny rail for scope and accessories ( e. g. night sight attachment) is attached above the receiver and barrel cover. The rifle can be equipped with any scope required.

Sub assemblies

1. receiver with bolt and barrel
2. barrel shroud with fore-end
3. grip frame
4. but stock
5. magazine
6. bi-pod
7. scope with scope mount

Caliber(s): 7.62x51mm NATO (.308Win), .300 Winchester Magnum, .338 Lapua Magnum
Operation: bolt action
Barrel: 660 mm
Weight: 5.9 kg unloaded, without scope
Length: 990 mm
Feed Mechanism: 5 (.308) or 4 (.300WM and .338LM) rounds detachable box magazines
